Speed Gate Drive
>
APS4808 DC24V 48V 8A 24A Incremental Encoder Servo Motor Drive For Wing Gate

APS4808 DC24V 48V 8A 24A Incremental Encoder Servo Motor Drive For Wing Gate

Brand Name: Jiayu
Model Number: APS4808
MOQ: 2pcs
Price: Negotiable
Packaging Details: package
Payment Terms: TT
Detail Information
Place of Origin:
China
Certification:
CE
Features:
Low Noise
Input Voltage:
DC24/48V
Continuous/peak Current:
8A / 24A
Encoder Feedback:
Incremental
Communication Interface:
RS232/RS485/CAN
Digital Inputoutput:
4 Input/4 Output
Working Temperature:
-20℃ ~ 55℃
Built-in Regenerative Resistor:
12W
Supply Ability:
500pcs per month
Highlight:

Wing Gate DC Servo Motor Drive

,

Servo Motor Drive For Wing Gate

,

Incremental Encoder Servo Motor Drive

Product Description

dc 24 /48V 8 / 24 A incremental encoder servo drive for wing gate for hotel





Features

  • Adaptive low voltage servo motor, incremental encoder feedback input;
  • Integrated industry-leading channel movement control logic, real-time detection of movement status, to meet the requirements of safe passage;
  • For violent brake breaking and other use scenarios, the internal design of the brake module to ensure the stable work of the driver and power supply.
  • Supports multiple communication modes such as RS232, RS485 and CAN, provides Modbus communication protocol, and CAN interconnect with logic controller.
  • All terminals are designed with plug and pull type to ensure wiring safety and error;
  • Meet RoHS 2.0 specification;



Advantages

  • According to the narrow side appearance specially designed for the channel gate structure, the appropriate installation position can be selected according to the whole machine structure.
  • Support single machine operation, to meet the control requirements of unilateral structure;
  • Suitable for flap door, shear door and other standard channel gate;
  • Supporting JMC1514 channel controller, constitute a complete channel gate electronic control system;
  • Provide control protocol, can be adapted to the common logic control board;
  • Support servo debugging MagicServo, built-in oscilloscope for motion control and parameter monitoring;



Specification

Product name   servo drive
Warranty
3months-1year
Certification
ce
Place of Origin
China
input voltage
DC24/48V
Continuous/peak current
8A / 24A
Encoder feedback
incremental
communication interface
RS232/RS485/CAN
Digital inputoutput
4 input/4 output
operation panel
5 digit digital tube +5 independent keys
Working temperature
-20℃ ~ 55℃
Built-in regenerative resistor
12W
Application
swing barrier gate, turnstile





APS4808 DC24V 48V 8A 24A Incremental Encoder Servo Motor Drive For Wing Gate 0

Company profile

Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.









Welcom to ask us for more detail information of the products.
