Product Details
Place of Origin: China
Brand Name: Jiayu
Certification: CE
Model Number: EBS59R-A6
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: package
Delivery Time: 10-15days after payment
Payment Terms: TT
Supply Ability: 500pcs per month
Usage: |
Swing Gate Turnstile Servo Motor |
Keywords: |
Brushless Dc Electric Motor |
Construction: |
Permanent Magnet |
Commutation: |
Brushless |
Protect Feature: |
Drip-proof |
Typical Applications: |
Sliding Door |
Torque: |
0.5NM |
Speed(RPM): |
41RPM |
Continuous Current(A): |
6A |
Rated Voltage: |
DC24V |
Usage: |
Swing Gate Turnstile Servo Motor |
Keywords: |
Brushless Dc Electric Motor |
Construction: |
Permanent Magnet |
Commutation: |
Brushless |
Protect Feature: |
Drip-proof |
Typical Applications: |
Sliding Door |
Torque: |
0.5NM |
Speed(RPM): |
41RPM |
Continuous Current(A): |
6A |
Rated Voltage: |
DC24V |
►High-resolution position feedback with 2400 lines can realize accurate positioning Service life is not less than
►6 million times. Authoritative appraisal by third party testing institution.
►300mm acrylic door panel, opening time up to 0.3 seconds.
►Cooperate with the servo vector algorithm, can achieve sensitive anti-pinch protection.
Application
① Airports
② Ports
③ Railway station
④ Subway station
⑤ Bus station
⑥ Commercial building
⑦ Residential communities
⑧ School
⑨ Expressway station
Specification
|
item
|
value
|
|
Warranty
|
3months-1year
|
|
Place of Origin
|
China
|
|
Brand Name
|
JIAYU
|
|
Model Number
|
EBS59R-A6
|
|
Usage
|
BOAT, Car, Electric Bicycle, Home Appliance, Cosmetic instrument, SMART HOME
|
|
Certification
|
ce
|
|
Type
|
SERVO MOTOR
|
|
Torque
|
0.5NM
|
|
Construction
|
Permanent Magnet
|
|
Commutation
|
Brushless
|
|
Protect Feature
|
Drip-proof
|
|
Speed(RPM)
|
41RPM
|
|
Continuous Current(A)
|
6A
|
|
Efficiency
|
IE 2
|
|
Product Name
|
Servo Motor
|
|
Application
|
Electric Car Vehicle
|
|
Rated voltage
|
DC24V
|
|
Rated power
|
100W
|
|
Continuous rated speed
|
2000RPM
|
|
Continuous rated torque
|
0.5NM
|
|
Continuous rated current
|
6A
|
|
Peak curren
|
12A
|
|
Output speed
|
41RPM
|
|
Output torque
|
23NM
|
Company profile
Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.
FAQ
1.Are you Factory or Trader?
we are factory,and have professional R.&D team as introduced in company information.
2.How can we guarantee quality?
Always a pre-production sample before mass production;Always final Inspection before shipment.
3. What can you buy from us?
Access servo drive,speed gate drive,turnstile controller,swing gate drive,barrier gate controller,servo motor,mechanism.
4. Why should you buy from us not from other suppliers?
We are with multiple invention patents and software copyrights such as servo drive and channel gate controltechnology.
Committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automaticgate control movement.
5. What is your after-sale service?
Free maintance within 12 months guarantee,lifetime consultant,Professional solutions in installation and maintance.
6.Do you get the relevant certifications?
All products are made according to ISO90o1,CE requirements.
7.How about the delivery?
-Sample:3-5days
-Bulk order:15-30 days.
