Product Details
Place of Origin: China
Brand Name: Jiayu
Certification: CE
Model Number: APS2AC05
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: package
Delivery Time: 10-15days after payment
Payment Terms: TT
Supply Ability: 500pcs per month
Type: |
SERVO MOTOR |
Phase: |
Single-phase |
Protect Feature: |
Explosion-proof |
AC Voltage: |
220V |
Efficiency: |
IE 4 |
Encoder Feedback: |
Incremental 2500-line |
Communication Port: |
RS232,RS485,CAN |
Control Method: |
Pulse,Modbus,CANbus |
Type: |
SERVO MOTOR |
Phase: |
Single-phase |
Protect Feature: |
Explosion-proof |
AC Voltage: |
220V |
Efficiency: |
IE 4 |
Encoder Feedback: |
Incremental 2500-line |
Communication Port: |
RS232,RS485,CAN |
Control Method: |
Pulse,Modbus,CANbus |
|
Model
|
APS 2AC05
|
|
Rated Power
|
750W
|
|
Current
|
5A
|
|
Maximum Current
|
15A
|
|
Input power
|
Single phase 220VAC
|
|
Encoder feedback
|
Incremental 2500-line
|
|
Communication port
|
RS232,RS485,CAN
|
|
Pulse type
|
Pulse + direction
|
|
IO port
|
9 inputs, 5 outputs, optocoupler isolation
|
|
Control method
|
Pulse,Modbus,CANbus
|
|
Working temperature
|
-20 ~ 55℃
|
Installed Size:
Company profile
Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.
