24V 8A Drip Proof DC Servo Drive For Speed Gate Turnstile

Product Details

Place of Origin: China

Brand Name: JIAYU

Certification: CE

Model Number: EPS2408-AD

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: pakeage

Delivery Time: 10-15days after payment

Payment Terms: TT

Supply Ability: 500pcs per month

Get Best Price
Highlight:

Drip Proof DC Servo Drive

,

Speed Gate Turnstile DC Servo Drive

,

24V 8A Serve Drive

Input Voltage:
DC 15 ~ 30V
Rated / Peak Current:
8A / 24A
Feedback:
Incremental Encoder With HALL
Communication:
RS232/RS485/CAN
Digital I/O:
4 IN 3 OUT, Optocouplers Isolation
Special Interface:
1 Output For Clutch Brake
Hardware Protection:
Lowvoltage, Overvoltage, Overcurrent, Overheating
Working Temperature:
-10℃ ~ 55℃
Product Name:
Servo Drive
Application:
Industrial Automation
Input Voltage:
DC 15 ~ 30V
Rated / Peak Current:
8A / 24A
Feedback:
Incremental Encoder With HALL
Communication:
RS232/RS485/CAN
Digital I/O:
4 IN 3 OUT, Optocouplers Isolation
Special Interface:
1 Output For Clutch Brake
Hardware Protection:
Lowvoltage, Overvoltage, Overcurrent, Overheating
Working Temperature:
-10℃ ~ 55℃
Product Name:
Servo Drive
Application:
Industrial Automation
24V 8A Drip Proof DC Servo Drive For Speed Gate Turnstile
DC Servo Drive 24v 8A incremental drip-proof serve drive for speed gate turnstile

Features of DC Servo Drive
  • Adaptive low voltage DC servo motor, incremental encoder feedback interface;
  • Integrated industry-leading swing brake and wing brake channel movement module control logic, real-time detection of motion state, to meet the requirements of safe passage;
  • For violent brake breaking and other use scenarios, the internal design of a special module to ensure the stable work of the driver and power supply.
  • It supports RS232, RS485, CAN and other communication modes, provides Modbus communication protocol, and CAN interconnect with channel controller.
  • Support multiple driver networking, can be used for double door or more channel gate;
  • Supporting digital key box, LCD key box and other debugging tools;

Advantages of DC Servo Drive

Jiayu supply and install a wide range of quality and innovative products that help ensure your premises are safe and secure. From anti-tailgating products such as swing barrier gate and turnstile to our infrared sensor , we have a product to suit you.

  • Support single machine operation, to meet the control requirements of unilateral structure;
  • Suitable for swing brake, wing brake, three roller brake and other standard channel brake;
  • Support multiple driver networking, can realize multiple groups of gate combination control;
  • It can be matched with JMC1514 channel controller to form the industry-leading channel gate electronic control system;
  • Modbus communication protocol is provided, which can be adapted to the third party control board.

 24V 8A Drip Proof DC Servo Drive For Speed Gate Turnstile 0



Specification of DC Servo Drive

Brand Name
JIAYU
Model Number
EPS2408-AD
Input Voltage
DC 15 ~ 30V
Rated / Peak Current
8A / 24A
Feedback
Incremental Encoder with HALL
Communication
RS232/RS485/CAN
Digital I/O
4 IN 3 OUT, Optocouplers Isolation
special interface
1 output for clutch brake
Hardware Protection
Lowvoltage, Overvoltage, Overcurrent, Overheating
Working Temperature
-10℃ ~ 55℃
Product name
Servo Drive
Application
Industrial Automation



Dimension of DC Servo Drive

24V 8A Drip Proof DC Servo Drive For Speed Gate Turnstile 1

Company profile

Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.



In the channel gate equipment industry, tens of thousands of electronic control products developed and manufactured by Jiayu Mechatronic Co., Ltd. have been shipped on supporting customers' complete equipment, which are spread all over the country, as well as overseas regions such as Europe, Middle East, and Southeast Asia. The field has contributed a lot.



In the future, the company will focus more on the improvement of product performance and quality, and continue to build the top brand of electronic control of channel gates.

24V 8A Drip Proof DC Servo Drive For Speed Gate Turnstile 3



Application of DC Servo Drive

24V 8A Drip Proof DC Servo Drive For Speed Gate Turnstile 4



FAQ

Q1: Can I install it myself?
A: Yes, it will be easy to install. We will have installation instructions and videos.
Q2: Is the product waterproof?
A: Yes, our products are waterproof and can be used outdoors.
Q3: Are you a distributor or a manufacturer?
A: Hello,we are A manufacturer, the factory sells directly, the price and service have advantages.

Q4: How is the freight calculated?
A: It varies according to the delivery address. For details,you can consult the online
customer service staff.
Q5: How long is the production cycle?
A: Conventional products are basically available in stock, and the production cycle of customized products is about one week.
