Home > products > Speed Gate Motors > Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC

Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC

Product Details

Place of Origin: China

Brand Name: Jiayu

Certification: CE

Model Number: EBS59R-100A-20XP4J-B6EL-S1-00

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: package

Delivery Time: 10-15days after payment

Payment Terms: TT

Supply Ability: 500pcs per month

Get Best Price
Highlight:

100 Watt Servo Motor Position Feedback

,

Servo Motor Position Feedback 24VDC

,

0.5N.M 100 Watt Servo Motor

Type:
SERVO MOTOR
Torque:
23N.m
Protect Feature:
Waterproof
Speed(RPM):
2000rpm
Continuous Current(A):
6A
Rated Voltage:
24VDC
Rated Power:
100Watt
Continuous Rated Torque:
0.5N.m
Peak Current:
12A
Output Speed:
41rpm
Encoder Resolution:
9600ppr
Weight Of Motor:
1.3kg
Type:
SERVO MOTOR
Torque:
23N.m
Protect Feature:
Waterproof
Speed(RPM):
2000rpm
Continuous Current(A):
6A
Rated Voltage:
24VDC
Rated Power:
100Watt
Continuous Rated Torque:
0.5N.m
Peak Current:
12A
Output Speed:
41rpm
Encoder Resolution:
9600ppr
Weight Of Motor:
1.3kg
Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC

Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC



Product description

turnstile servo motor series are designed to working with swing barrier gate, speed gate and tripod turnstile control pedestrian entering and exiting, adopts 2400 lines encoder, suitable for indoor and outdoor situation, easy to install, and the dc servo motor widely use for applications like stadium, apartment, gym, museum, station, library and factory etc.


Specification
Model Number
EBS59R-100A-20XP4E-B6EL-S1-00
Type
SERVO MOTOR
Torque
23N.m
Construction
Permanent Magnet
Protect Feature
Waterproof
Speed(RPM)
2000rpm
Continuous Current(A)
6A
Rated voltage
24VDC
Rated power
100Watt
Continuous rated speed
2000rpm
Continuous rated torque
0.5N.m
Continuous rated current
6A
Peak current
12A
Output speed
41rpm
Output torque
23N.m
Encoder resolution
9600ppr
Weight of motor
1.3kg

Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC 0

Why choose us

1. Our price is reasonable;

2. We can accept small orders;

3. Sample order delivery time is in 5 days, mass quantity order lead time is 7-10 days;

4. We can accept payment via paypal, T/T and L/C;

5. Our products quality assurance is 1 year, and we can provide you professional technical support;

6. We accept products customize.



Dimension


Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC 3




Speed Gate Motors 0.5N.M 100 Watt Servo Motor Position Feedback 24VDC 9

Company profile

Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.
