Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment.

Brand Name:	CSJY
Model Number:	GAL400
MOQ:	2
Price:	Negotiation
Packaging Details:	carton
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, Rohs

Features:

Compact Design

Rated Voltage:

DC48v

Rated Power:

Rated Speed:

3000rpm

Rated Torque:

0.64nm

Flange Size:

Encoder Type:

Incremental Encoder

Protocol:

RS232 RS485 CANopen

Motor Brake:

Optional

Application:

Automatic Device

Supply Ability:

5000/year

Product Description

Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment.

Products features:1. Integrated servo drive and servo motor in one, small size;
2. Support RS485 /CAN bus communication, support pulse input,can be used for multi-axis equipment control;

3. Abudant Dl and DO interfaces to meet market requirements.

Power input	DC24~50V (48V)
Rated power(W)	400W
Rated speed(rpm)	3000RPM
Communication type	RS485,CAN
Ambient temperature	-25℃~55℃
Rated torque(Nm)	1.27Nm
Encoder feedback	2500 line incremental encoder

Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment. 0

Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment. 1

Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment. 2

Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment. 3

Integrated Servo Motor And Servo Driver, 48V 400W Compact Design Motor Driver For Automated Equipment. 4
