High Torque DC Servo Motor
>
5.6Nm 0.3s High Speed Servo Motor 120RPM For Automatic Turnstile Gates

5.6Nm 0.3s High Speed Servo Motor 120RPM For Automatic Turnstile Gates

Brand Name: Jiayu
Model Number: EBS80F-70A-01DC5Z-BFEL-ST-00
MOQ: 2pcs
Price: Negotiable
Packaging Details: package
Payment Terms: TT
Detail Information
Place of Origin:
China
Certification:
CE
Opening And Closing Speed:
0.3s
Product Name:
Servo Motor For Turnstile Gates
Model Number:
EBS80F-70A-01DC5Z-BFEL-ST-00
Encoder Feedback:
2500
Rated Speed:
120RPM
Insalation Grade:
B
Torque:
5.6nm
Rated Power:
70W
Supply Ability:
500pcs per month
Highlight:

0.3s High Speed Servo Motor

,

High Speed Servo Motor 120RPM

,

5.6Nm Turnstile motor

Product Description
Fast speed Servo Motor 0.3s for automatic turnstile gates


Product description

turnstile gate motor EBS80F series are designed to working with swing barrier gate, speed gate and tripod turnstile control pedestrian entering and exiting, adopts 2400 lines encoder, suitable for indoor and outdoor situation, easy to install, and the bldc servo motor widely use for applications like stadium, apartment, gym, museum, station, library and factory etc.


Features
►The noise is as low as 30 decibels, the torque is 5.6 NM, and the door opening speed is up to 0.3 seconds;
Voltage DC24V, human body safety voltage, no leakage risk;
Servo direct drive motor, torque is up to 5.6Nm, and the rotor is made of strong magnetic materials;
Door opening and closing life of 30 million times;
High and low temperature resistance, -25 degrees to 70 degrees;

Specification
item
value
Warranty
3months-1year
Place of Origin
China
Brand Name
jiayu
Model Number
EBS80F-70A-01DC5Z-BFEL-ST-00
Usage
flap barrier gate
Certification
ce, RoHS
Type
SERVO MOTOR
Torque
5.6nm
Construction
Permanent Magnet
Protect Feature
Waterproof
Speed(RPM)
100RPM
Continuous Current(A)

 5.9A

Efficiency
IE 2
Product Name
dc servo motor
Rated Voltage
dc 24v
Power
70w
Rated Current
5.9A
Rated torque
5.6nm
Noise
Low Noise Level
Application
speed gate turnstile
Feature
Long Life Time
Diameter
80mm
Rated speed
100rpm

5.6Nm 0.3s High Speed Servo Motor 120RPM For Automatic Turnstile Gates 15.6Nm 0.3s High Speed Servo Motor 120RPM For Automatic Turnstile Gates 25.6Nm 0.3s High Speed Servo Motor 120RPM For Automatic Turnstile Gates 3

Company profile

Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.

5.6Nm 0.3s High Speed Servo Motor 120RPM For Automatic Turnstile Gates 4

FAQ

1.Are you Factory or Trader?
we are factory,and have professional R.&D team as introduced in company information.
2.How can we guarantee quality?
Always a pre-production sample before mass production;Always final Inspection before shipment.
3. What can you buy from us?
Access servo drive,speed gate drive,turnstile controller,swing gate drive,barrier gate controller,servo motor,mechanism.
4. Why should you buy from us not from other suppliers?
We are with multiple invention patents and software copyrights such as servo drive and channel gate controltechnology.
Committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automaticgate control movement.
5. What is your after-sale service?
Free maintance within 12 months guarantee,lifetime consultant,Professional solutions in installation and maintance.
6.Do you get the relevant certifications?
All products are made according to ISO90o1,CE requirements.
7.How about the delivery?
-Sample:3-5days
-Bulk order:15-30 days.
