GMBC2406 Turnstile Gate Control Board for Flap Gates

Brand Name:	CSJY
Model Number:	GMBC2406
MOQ:	2
Price:	Negotiate
Packaging Details:	cartons
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Input Power Supply:

DC24V, Dual Power Connection, 150W/6.5A On One Side Is Recommended; Single Power Connection, 300W Recommended

Adaptor Motor:

DC Brushless Motor Below 60W With 2400-line Position Feedback

Communication Mode:

RS232 Serial Communication, Supporting Modbus Protocol

Power-off:

DC12V Battery, Or Optional Super Capacitor Module

Infrared Sensor:

6 Independent Interfaces, PNP, NPN Normally Open, Open Collector Type

Voice Output:

External 8W 4Ω Speaker

Anti-pinch Protection:

Current+position Double Detection, Adjustable Sensitivity

Control Effect:

The Open Speed Is Fast, And It Is Stable And Does Not Shake

Working Environment:

-20℃ ~ 55℃

Application:

Swing Gate, Speed Gate, Tripod Turnstile, Sliding Gate

Supply Ability:

5000pcs/month

Highlight:

MBC2406 Turnstile Gate Control Board

Turnstile Gate Control Board

Flap Gates Turnstile Gate Control Board

Product Description

MBC2406 Turnstile Gate Control Board for Flap Gates

Product description

This system consists of access gate control board, brushless servo motor, servo control technology, real-time

detection of motor position, self-learning load curve without external encoder, physical anti-pinch protection and

adjustable sensitivity. Support access mode settings such as card swiping, freedom and prohibition at the entrance and exit;It has the logic detection of illegal intrusion, trailing traffic, detention, reverse traffic, infrared anti-pinch, etc., and is suitable for access gate equipment such as speed gate/swing gate, flap gate/sliding gate, etc.

Technical parameter

Input power supply	DC24V, dual power connection, 150W/6.5A on one side is recommended; Single power connection, 300W recommended;
Adaptor motor	DC brushless motor below 60W with 2400-line position feedback
Communication mode	RS232 serial communication, supporting Modbus protocol
Power-off	DC12V battery, or optional super capacitor module
Infrared sensor	6 independent interfaces, PNP, NPN normally open, open collector type
Voice output	external 8W 4Ω speaker
Working environment	-20℃ ~ 55℃, humidity below 90% (no condensation)

GMBC2406 Turnstile Gate Control Board for Flap Gates 0

GMBC2406 Turnstile Gate Control Board for Flap Gates 1

Application

This control board suitable for swing gate, speed gate, sliding gate, tripod turnstile, etc

GMBC2406 Turnstile Gate Control Board for Flap Gates 2

GMBC2406 Turnstile Gate Control Board for Flap Gates 3

RFQ

1: Are you trading company or manufacturer ?

We are a professional barrier gate manufacturer, our experience more than 10 years.

2. Do you provide OEM service?

Yes, we can offer OEM services as follows: 1) We can print your logo on barrier gate. 2) We can customize barrier arm size to your needs.

3. Lead time for standard item?

1-50 sets: 3-5 working days; 50-100 sets: 6-10 working days; 100-500sets: 11-20 working days. For custom-made logo, 3-10 working days longer.

4. Do you provide quality guarantee/warranty and after sale service?

We have a one-year standard warranty, excellent after-sales service.

5. Do you provide samples ?

No,we don't provide free samples. The MOQ of our products is 1pc.

6. How about the payment method?

T/T or Alibaba.

7. What kind of technical support you would provide?

We have professional R&D and technical team,you have any technical problem of product.

8. How to ship?

By air or by sea, quantity over 10 sets better to choose by sea to reduce cost.
